Manufacturer: Goldhofer

Type: STHP/SL 4 & SL6

WEIGHT THP SL4

• Maximum axle load: 45.000 kg per axle
• Total Axle Load: 4x 45.000 kg = 180.000 kg.
• GVW: 180.000 kg.
• Empty weight: 19.400 kg.
• Loading capicity: 166.150 kg.

MEASUREMENTS THP/ SL 4

• Total Lenght: 10.250 mm.
• Loading floor width: 3.000 mm.
• Height: 1.175 mm. (+/- 300)

WEIGHT THP SL6

• Maximum axle load: 45.000 kg per axle
• Total Axle Load: 6x 45.000 kg = 270.000 kg.
• GVW: 270.000 kg.
• Empty weight: 19.800 kg.
• Loading capicity: 250.200 kg.

MEASUREMENTS THP/ SL 6

• Total Lenght: 13.250 mm.
• Loading floor width: 3.000 mm.
• Height: 1.175 mm. (+/- 300)

Main Features Gooseneck

• Loading platform (3.700 mm x 2.440 mm)
• 3.5 inch 5th wheel
• Lifting and lowering by means of hydraulic, including hydraulic supporting cylinders
• Coupling height 1.450 mm.
• Integrated lashing coupling
• Lashing rings
• Spare wheel + Spare wheel carrier
• Hydraulic locking pin to connect the gooseneck
• Auto lube for gooseneck with pump, Beka-MAX
